Hexapod Access Gantry for Confined Spaces

 Hexapod Access Gantry for Confined Spaces

The Hexapod Access Gantry is designed for safe entry, rescue, and lifting operations in confined spaces with large openings and below-ground environments. Its robust construction and versatile features ensure stability and efficiency in challenging conditions.

• Adjustable Height: Ranges from 1.15 m to 2.15 m.
• Expandable Wheelbase:
• Single Tripod: 1.08 m to 1.62 m.
• Dual Tripod: 1.80 m to 4.20 m.
• Maximum Load Capacity:
• 500 kg under the tripod head.
• 250 kg on individual legs.

• Pulley System: Integrated at the tripod head for seamless winch cable operation.
• Anchorage Rings: Three anchorage rings on the tripod head for flexible application.
• Durable Materials:
• Aluminium alloy tripod head and feet for lightweight strength.
• Articulated steel soles with rubber pads for increased stability and friction.
• High Resistance: Anchor points tested to withstand >13 kN.

• Compatible with various winches, including FA 60 003 20, FA 60 003 30, FA 60 023 20, and FA 60 023 20R.
• Can be used with universal plates (FA 60 101 01) or adaptation kits (FA 60 001 02/03/04).
• Supports self-retracting fall arresters with integrated rescue winches (e.g., FA 20 401 10/S, FA 20 401 20/R/S, FA 20 401 30/S).

• Moulded aluminium alloy tripod head for durability.
• Supplied with a dedicated carry bag for ease of transport and storage.
• Applications
• Ideal for confined space entry, rescue operations, and lifting tasks in industrial, construction, and maintenance environments.

The Hexapod Access Gantry sets a new standard in confined space safety, combining advanced engineering with user-friendly features. Designed to adapt to the most demanding situations, it ensures maximum efficiency without compromising on safety.
