This model is suitable for tasks such as roof access, solar panel installation, ladder-based work, and industrial maintenance. It is fully compliant with EN 360:2002 and approved for users up to 140kg.
Key Features
- 20m galvanised steel wire rope (4.5mm diameter) for dependable vertical fall protection.
- Internal braking mechanism designed to keep fall arrest forces below 6kN.
- Impact-resistant polymer casing for durability in industrial environments.
- Inspection window for accessing the internal mechanism without opening the full casing.
- Load indicator connector to show if the device has experienced a significant fall.
- Swivel anchorage connector to reduce rope twisting and improve user movement.
- Guiding cord included for easy rewinding of the wire rope after use.
- Ergonomic carrying handle and gripping handle for easier transport and setup.
Technical Specifications
| Manufacturer | Kratos Safety |
|---|---|
| Product Code | FA 20 402 20 |
| Product Type | Wire rope retractable fall arrester |
| Working Length | 20m |
| Rope Type | Galvanised steel wire rope, 4.5mm diameter |
| User Capacity | Up to 140kg (vertical use only) |
| Minimum Breaking Strength | > 12kN |
| Fall Arrest Force | Less than 6kN (with internal braking) |
| Unit Weight | Approx. 7.43kg |
| Compliance | EN 360:2002 |
| HS Code | 84798997 |
Compliance & Safety
The Kratos Safety 20m retractable fall arrester meets the requirements of EN 360:2002. Its braking mechanism is engineered to keep fall arrest forces low, helping protect both the user and the anchorage system in a fall event.
A built-in load indicator on the connector provides a clear visual sign if the unit has been exposed to a heavy fall. If activated, the device must be withdrawn from service for inspection by a competent, approved technician.
This fall arrester should always be used with a certified full body harness and within a complete fall protection system that includes a safe anchorage and a rescue plan.
Typical Applications
This device offers reliable vertical fall protection for a wide range of work-at-height tasks, including:
- Roof access and roof-top maintenance.
- Solar panel installation and servicing.
- Water treatment and wastewater facilities.
- Telecommunications masts and tower climbing.
- Vertical fixed-ladder systems (where compatible).
- Industrial plant and general maintenance work.
Important Usage Note – Vertical Use Only
This model is approved for vertical use only. It is not suitable for horizontal, edge-based or overhead applications unless otherwise specified by Kratos Safety. Prolift can advise on alternative systems for horizontal lifeline and overhead work.
FAQs
1. Is this fall arrester suitable for horizontal use?
No. This Kratos model is designed exclusively for vertical applications. Horizontal and over-edge use require different fall protection equipment.
2. What is the maximum user weight?
The maximum approved user weight is 140kg.
3. Does the fall arrester include a connector?
Yes. The unit is supplied with a load-indicator connector at the anchorage end and a swivel connector at the user end.
4. Can the wire rope be serviced?
The casing includes an inspection window giving access for authorised servicing. Only qualified personnel should carry out maintenance.
5. How often should it be inspected?
The unit should be inspected before each use and undergo periodic formal inspection by a competent person in line with company procedures and regulations.
